Straight-Through Diaphragm Valve Technical Datasheet
(Non-Weir, Reduced-Bore Design)
Compliance: BS5156 ∙ Materials: Ductile Iron + Full EPDM Lining
|
Component
|
Material & Specification
|
Key Properties
|
|
1. Valve Body
|
Ductile Iron (EN-GJS-400-18/GGG40)
• Full Internal Lining: EPDM (3 mm min. thickness)
|
• Pressure Rating: PN10/PN16
• Lining Adhesion: ≥ 5 MPa (ISO 4624)
• Corrosion Protection: Full EPDM barrier
|
|
2. Disc
|
Ductile Iron (GGG40)
• EPDM-Encapsulated
|
• Reduced-Bore Design: 85–90% of pipe ID
• Abrasion-Resistant Surface
|
|
3. Stem
|
AISI 316L Stainless Steel
• Mechanically Polished (Ra ≤ 1.6 μm)
|
• SSC-Resistant (NACE MR0175)
• Hardness: 140–180 HB
|
|
4. Diaphragm
|
Hypalon
• Polyester Fabric Core
|
• Temp Range: -20°C to +130°C
• Cycle Life: ≥ 50,000 cycles
|
|
5. Bonnet
|
Ductile Iron + Full EPDM Lining
|
• Bolted Design (EPDM-Coated Bolts)
|
|
6. Seals
|
EPDM O-Rings/Gaskets
|
• Bubble-Tight Shutoff (ISO 5208 Rate A)
|
Critical Technical Data
|
Parameter
|
Specification
|
|
Flow Path Design
|
Straight-Through (Non-Weir) ∙ Bore: 85–90% of nominal pipe ID
|
|
Size Range
|
DN50 to DN200 (2″ to 8″)
|
|
End Connections
|
• Flanged (EN 1092-1 Type A) ∙ ANSI Class 150
• Optional: Lug/Wafer
|
|
Flow Coefficient
|
DN100 (4″): Cv ≈ 120 (vs. 180 for full-bore)
|
|
Pressure Drop
|
ΔP ≈ 0.3–0.8 bar (water, 2 m/s flow)
|
|
Actuation
|
Manual Handwheel ∙ Pneumatic (Spring-Return) ∙ Electric (On/Off)
|
|
Certifications
|
PED 2014/68/EU (Cat. II) ∙ ISO 9001 ∙ EN 10204 3.1
|
Straight-Through vs. Full Bore: Key Differences
|
Feature
|
Straight-Through Valve
|
Full-Bore Valve
|
|
Bore Diameter
|
85–95% of pipe ID
|
100% of pipe ID
|
|
Flow Efficiency
|
Moderate (Cv ≈ 65% of full-bore)
|
Maximum (No restriction)
|
|
Slurry Handling
|
Good (Less clogging than weir-type)
|
Excellent (Zero clogging risk)
|
|
Mechanical Strength
|
Higher (Thicker walls due to reduced bore)
|
Lower (Thinner walls to match pipe ID)
|
|
Cost
|
Lower (Less material)
|
Higher
|
Design Advantages of Straight-Through Configuration
- Optimized for Slurries & Viscous Fluids
- Smooth, obstruction-free flow path prevents particle buildup (e.g., wastewater sludge, pulp).
- Robust Pressure Containment
- Thicker ductile iron walls (enabled by reduced bore) withstand surge pressures up to 1.5×PN.
- Simplified Maintenance
- Top-entry diaphragm replacement (no pipe disassembly).
- Cost-Effective Corrosion Protection
- Full EPDM lining isolates ductile iron from corrosive media (pH 3–12).
Limitations & Design Notes
- Not Pigable: Reduced bore prevents pipeline pigging.
- Chemical Limits: EPDM incompatible with oils, aromatics, concentrated acids (>20% H₂SO₄).
- Temperature: Max. 130°C (EPDM) – derate pressure above 80°C.
- Actuator Sizing: Higher torque required vs. weir-type due to larger diaphragm area.
