1″-800LB F22 Y Pattern Strainer

TECHNICAL DATA SHEET

Product Name: 1-inch 800LB F22 Alloy Steel Y Pattern Strainer
Model/Specification: 1″-800LB-F22-Y-STRAINER
Product Type: Y Type Strainer (Forged)
Connection Type: Threaded (NPT) / Socket Weld (SW) / Butt Weld (BW) User specified

1. Basic Design Parameters

2. Technical Specifications

3. Material of Construction (F22 Alloy Steel)

4. Main Dimensions & Connection Details

Note: Dimensions are for 1″ Forged Y Strainer. Values are based on industry standards and may vary by manufacturer .

4.1 End-to-End Dimensions (Face-to-Face)

*Note:

• L dimension typically ranges from 98mm to 111mm for 1″ Class 800 strainers .
• H dimension (height from centerline to bottom of bonnet) approximately 70-100mm .*

4.2 End Preparation Details (Per ASME Standards)

4.3 Screen Details

5. Pressure-Temperature Rating (ASME B16.34 / Class 800)

*Material Group: Alloy Steel – ASTM A182 F22 (1.25Cr-0.5Mo / 2.25Cr-1Mo)*

*Note: F22 alloy maintains strength at elevated temperatures, suitable for high-temperature steam and hydrocarbon service.*

6. Test Pressure (API 598)

7. Flow Characteristics & Pressure Drop

8. Features & Applications

• Key Features:
• High-Temperature Alloy Construction (F22): Chrome-Molybdenum alloy steel (ASTM A182 F22) provides excellent strength and oxidation resistance at elevated temperatures up to 550°C, making it ideal for high-temperature steam and hydrocarbon services .
• Forged Body: Forged construction ensures superior strength, grain structure integrity, and freedom from porosity, critical for high-pressure Class 800 applications .
• Y Pattern Design: Compact Y-shaped body minimizes pressure drop while providing effective debris removal .
• Removable Stainless Steel Screen: Easy maintenance – screen can be removed for cleaning without removing the strainer from the pipeline .
• Bolted / Screwed Bonnet: Secure seal design with high-temperature gasket (graphite) for reliable operation .
• Multiple End Options: Available in NPT threaded, socket weld, or butt weld connections to suit various piping specifications .
• Equipment Protection: Protects downstream equipment such as control valves, pumps, steam traps, and flow meters from damaging debris .
• Versatile Installation: Can be installed in horizontal or vertical (downward flow) pipelines .
• Customizable Filtration: Standard 20 mesh screen with optional finer meshes (40, 60, 80, 100) or perforated screens available based on application requirements .
• Main Applications:
• High-Temperature Steam Systems: Power plants, boiler houses, steam distribution networks .
• Refineries & Petrochemical Plants: Hydrocarbon processing, high-temperature oil and gas lines.
• Thermal Oil / Heat Transfer Systems: Protecting pumps and heaters from debris .
• Process Industry: Chemical processing, high-temperature fluid filtration.
• Upstream of Critical Equipment: Installed before control valves, steam traps, flow meters, and pumps .
• Condensate Lines: Removing rust and scale from condensate return systems .

*Disclaimer: The above data is prepared based on common industry standards (API 602, ASME B16.34) for forged alloy steel Y strainers. Specific dimensions, materials, and pressure ratings may vary by manufacturer. F22 alloy is specially suited for high-temperature service up to 550°C. The final technical agreement and certified drawings shall prevail.*
