CNG LNG LPG Pattern forged globe valve

PHOTO SHOWS SPECIFICATION AS BELOW
SIZE: 1″
RATING: 800LB
END: SW AS PER ASME B16.11
TEMPERATURE: -196 ℃
BODY AND BONNET : ASTM A182 F304
WEDGE: SOLID ASTM A182 F304+HF
STEM: ASTM A182 F304
SEAT: HF METAL
ACTUATION: HAND WHEEL

CNG LNG LPG Pattern forged globe valve

PHOTO SHOWS SPECIFICATION AS BELOW

SIZE: 1″

RATING: 800LB

END: SW AS PER ASME B16.11

TEMPERATURE: -196 ℃

BODY AND BONNET : ASTM A182 F304

WEDGE: SOLID ASTM A182 F304+HF

STEM: ASTM A182 F304

SEAT: HF METAL

ACTUATION: HAND WHEEL

Description

GENERAL

Size: 1/8″~4″.
Pressure Rating: 150LB~4500LB, PN6~PN750
Design Temperature: -196℃~800℃.
General applications: CNG, LNG,LPG, CO2, N2, other cryogenic duty.STEAM thermal duty.
Design & Manufacture: BS 6364, API 6D , ASME B16.34, API 602 are basic,other norms could be used according to orders.
F TO F dimensions: API 6D, ASME B16.10, BS EN 558
Connection: ASME B16.11, ASME B16.25, ASME B16.5, EN 1092, JIS 5K-20K. RF, RTJ are available.
Safety design: fire proof

GENERAL MATERIAL

BODY: ASTM A182 F304/F316/F304L/F316L/F51/F53, MONEL K400/K500, H276,INCONEL 625/718
PLUG: ASTM A182 F304, F316
SEAT: PCTFE, PEEK, HF METAL
OPERATOR: SPRING LOADED
OTHER SPECIAL MATERIALS ARE AVAILABLE TO CUSTOMIZE.

TEST

Inspection and approval norm: API598, API6D, BS6364.

QUALITY CONTROL:

100% Chemical analysis and mechanical test with raw materials of each heat numbers.
100% DPT test with the castings, partly MT or UT test, RT is always available if required.
100% hydraulic test with the shell and seal and low pressure air test.

GUATANTEE:

SAVVY VALVES is committed to delivering exceptional product quality and worry-free after-sales service. Our valves are guaranteed to provide a minimum service life of 12 months, during which we will supply all necessary spare parts and detailed maintenance instructions free of charge. Within the warranty period, if any non-human-induced damage occurs, we will replace components at no cost and provide professional technical support. After the warranty expires, customers only need to pay for the cost of spare parts, while still benefiting from discounted maintenance services. Our goal is to help clients reduce operational costs and enhance production efficiency through reliable quality and comprehensive after-sales support. Whether for technical inquiries or maintenance needs, our expert team will respond promptly to ensure your valve system maintains optimal performance at all times.

HOT SALE PRODUCTS

For over 10 years, we have been a leading supplier of industrial valves for major global projects in water supply, oil & gas, and desalination.

Why Is A CNG LNG LPG Pattern Forged Globe Valve Ideal For Cryogenic Applications?

The CNG LNG LPG pattern forged globe valve is engineered for reliable performance in cryogenic environments involving liquefied natural gas, petroleum gas, and compressed natural gas. Its pattern-forged body provides superior structural integrity, enhanced resistance to thermal shock, and a compact footprint suitable for space-constrained installations. Designed to handle extremely low temperatures, this valve features an extended bonnet that protects stem sealing components from cryogenic media and minimizes the risk of icing or leakage. The globe-style internal configuration allows for precise flow regulation and tight shut-off, which is crucial for controlling cryogenic gases safely and efficiently. High-quality materials with excellent low-temperature toughness are used throughout, ensuring durability and long service life. Whether used in LNG terminals, CNG fueling stations, or LPG storage facilities, this valve delivers dependable operation, excellent sealing, and easy integration with both manual and automated control systems.
