SAVVY Electric hydraulic actuated V port control ball valve

Electric hydraulic V port control ball valve

SAMPLE SPECIFICATIONS
SIZE:8″
RATING:300LB
BODY AND BONNET : ASTM A350 LF2
V-NOTCH BALL: ASTM A182 F316+TCC 90℃ NOTCH.
STEM: ASTM A564 17-4PH
SEAT: ASTM A182 F316+TCC
SPRING: INCONEL X-750
ACTUATION: ELECTRIC HYDRAULIC ACTUATOR

Description

GENERAL

Size: 2″ and above.
Pressure Rating: 150LB and above
Design Temperature: ASME B16.34 pressure temperature rating.
General applications: water, oil , gas

DESIGN

Design & Manufacture: API 6D , ASME B16.34 are basic,other norms could be used according to orders.
F TO F dimensions: API 6D, ASME B16.10, BS EN 558
Connection: ASME B16.5, B16.47, EN 1092, JIS 5K-20K. BW, RTJ are available.
Safety design: anti-static, fire proof, anti-blow out stem.
Additional: Double block and bleed.

GENERAL MATERIAL

BODY: ASTM A216 WCB.
BALL: ASTM A105+ENP, ASTM A182 F6A, F304, F316
STEM: ASTM A 182 F6A, F304,F316,XM-19, 17-4PH, INCONEL 718, MONEL K-500
SEAT COLLAR:ASTM A105+ENP, ASTM A182 F6A, F304, F316
SEAT INSERT: RPTFE, DEVLON,NYLON, MOLON,PEEK ETC.
SPRING: INCONEL X-750
OPERATOR: LEVER OR GEAR
OTHER SPECIAL MATERIALS ARE AVAILABLE TO CUSTOMIZE.

TEST

Inspection and approval norm: API598, API6D.

QUALITY CONTROL:

100% Chemical analysis and mechanical test with raw materials of each heat numbers.
100% DPT test with the castings, partly MT or UT test, RT is always available if required.
100% hydraulic test with the shell and seal and low pressure air test.

GUATANTEE:

SAVVY VALVES is committed to delivering exceptional product quality and worry-free after-sales service. Our valves are guaranteed to provide a minimum service life of 12 months, during which we will supply all necessary spare parts and detailed maintenance instructions free of charge. Within the warranty period, if any non-human-induced damage occurs, we will replace components at no cost and provide professional technical support. After the warranty expires, customers only need to pay for the cost of spare parts, while still benefiting from discounted maintenance services. Our goal is to help clients reduce operational costs and enhance production efficiency through reliable quality and comprehensive after-sales support. Whether for technical inquiries or maintenance needs, our expert team will respond promptly to ensure your valve system maintains optimal performance at all times.
