1″-800LB-Nipples 3-Piece Vacuum Floating Ball Valve

TECHNICAL DATA SHEET

1″-800LB-Nipples 3-Piece Vacuum Floating Ball Valve

1. Design Basis

1. Technical Specifications

III. Bill of Materials (Typical Options)

Note: Final material selection must conform to valve nameplate or manufacturer’s material certificate.

1. Dimensions & Weight (Reference)

• Face-to-face dimensions per ASME B16.10 or manufacturer’s standard.
• NPT threads conform to ASME B1.20.1.

1. Vacuum Performance

1. Key Features

1. 3-Piece Body Construction – Inline maintenance; internal seals and ball can be replaced without removing the valve from the pipeline.
2. Floating Ball Design – Line pressure pushes the ball against the downstream seat, ensuring bidirectional sealing.
3. Vacuum Suitability – Passes helium leak test with extremely low leak rate, suitable for high vacuum systems.
4. Anti-static Device – Electrical continuity between ball, stem and body (resistance ≤10Ω) prevents static build-up.
5. Blow-out Proof Stem – Bottom‑mounted stem with blow‑out proof design for safety.
6. Full Bore – Low flow resistance and pressure drop.
7. Multiple Material Options – Available in carbon steel, 304/316 stainless steel, duplex stainless steel, etc., for various corrosive media.

VII. Applications

• Petrochemical pipelines
• Vacuum coating, semiconductor equipment
• Laboratory high vacuum apparatus
• Pharmaceutical & bio‑engineering
• Food & beverage sanitary lines
• Power & energy

VIII. Testing & Inspection

1. Ordering Information

To ensure correct selection, please provide the following when ordering:

1. Nominal size (1″)
2. Pressure class (Class 800)
3. Body and trim material requirement (critical: specify e.g. A105 or 316SS)
4. End connection type (NPT / SW / BW)
5. Medium and temperature range
6. Vacuum requirement (working vacuum and allowable leak rate)
7. Actuation type (manual / pneumatic / electric)
8. Any additional requirements (fire safe, low emission, cleanliness level, etc.)

1. Remarks

• This technical data sheet applies to 1″-800LB-Nipples 3-Piece Vacuum Floating Ball Valve with unspecified material. The user shall refer to the actual valve nameplate or material certificate.
• For a detailed data sheet with a specific material (e.g. A105 or F316), the above can be supplemented with corresponding material parameters.
