3-Piece B62 C83600 Bronze Ball Valve

SAMPLE SPECIFICATIONS
SIZE:2″
RATING:600LB
BODY AND BONNET : B62
BALL: ASTM A182 F316
STEM: ASTM A182 F316
SEAT: PTFE
ACTUATION: WHEEL

Description

GENERAL

Size: 1/4″~4″.

Pressure Rating: up to 1500LB

Design Temperature: ASME B16.34 pressure temperature rating.

General applications: water, oil , gas

DESIGN

Design & Manufacture:ASME B16.34 are basic,other norms could be used according to orders.

F TO F dimensions: API 6D, ASME B16.10, BS EN 558

Connection: ASME B16.5, EN 1092, JIS 5K-20K. BW, RTJ are available.

Structure : SOLID DISC, OS&Y, BB, FB.

GENERAL MATERIAL

BODY AND BONNET: B62 .

DISC: B62

STEM: BRONZE OR STAINLESS STEEL

SEAT: B62

OPERATOR: WHEEL

OTHER SPECIAL MATERIALS ARE AVAILABLE TO CUSTOMIZE.

TEST

Inspection and approval norm: API598, API6D.

QUALITY CONTROL:

100% Chemical analysis and mechanical test with raw materials of each heat numbers.

100% DPT test with the castings, partly MT or UT test, RT is always available if required.

100% hydraulic test with the shell and seal and low pressure air test.

GUATANTEE:

SAVVY VALVES provide 12 months service life at least, free spares and maintenance instruction will be provided when required.

HOT SALE PRODUCTS

For over 10 years, we have been a leading supplier of industrial valves for major global projects in water supply, oil & gas, and desalination.

What Are The Benefits Of A 3-Piece B62 C83600 Bronze Ball Valve In Marine Or Water Systems?

The 3-piece B62 C83600 bronze ball valve offers excellent corrosion resistance and durability, making it ideal for marine, plumbing, and potable water applications. The C83600 bronze material, compliant with ASTM B62, provides reliable performance in saltwater and fresh water environments, while also being safe for drinking water use. The 3-piece design allows for easy disassembly and inline maintenance without disturbing pipe alignment, reducing system downtime. This structure is especially useful in applications requiring frequent cleaning or part replacement. The full-port ball ensures minimal pressure drop and smooth flow, while the compact size fits well in tight installations. Its combination of marine-grade corrosion resistance, ease of service, and flow efficiency makes it a trusted choice in shipbuilding, water distribution, HVAC systems, and general industrial use where bronze’s non-sparking and durable properties are required.
